Specification for 18 tonne tandem chassis.

  • Frame: RHS steel chassis, with drawbar beam and rear under run bar.
  • Axles: Tandem axles.
  • Brakes: 2-line air with S-cam brakes, auto-slack adjusters and system with spring application on park, and "push-to-manoeuvre" valve.
  • Anti-skid: Electronic Braking System with ISO 7638 connector & lead
  • Tyres: 385/65R22.5 tyres (super-singles)
  • Suspension: Full Air Suspension.
  • Coupling: 50 mm eye (to suit V.Orlandi 509 coupling)
  • Landing leg: Two-speed single-leg.
  • Electrics: Standard electrics to rear cluster lights, including front markers. (Side markers are not provided).
  • Finish: Temporary primer.
  • Crossbearers: Not supplied
  • Body: Not supplied.
  • Anti-spray/wings: Not supplied
  • Side Markers: Not supplied
